B245/B276/B277/B268/B269 Service Manual 18-Jan-06
25
One-tray Paper Tray Unit Installation
Accessory Check
Check the quantity and condition of the accessories against the following list.
No. Description Q’ty
1 Screw – M4 x 10 2
2 Stepped Screw – M4 x 10 2
3 Unit Holder 2
Installation Procedure
If the optional printer unit is installed:
Print out all data in the printer buffer.
Disconnect the network cable.
Unplug the machine power cord before starting the following procedure.
1. Remove the strips of tape. Make sure that you have removed all the strips of tape
and all the pieces of cardboard.
To Next Page
