Ricoh K-C3 - Two-Tray Paper Tray Unit; One-Bin Tray

B245/B276/B277/B268/B269 Service Manual 18-Jan-06
280
Two-Tray Paper Tray Unit
Paper Size A5 to A3, 5
1
/
2
" x 8
1
/
2
" SEF to 11" x 17"
Paper Weight: 60 – 105 g/m
2
, 16 – 28 lb
Tray Capacity: 500 sheets (80 g/m
2
, 20 lb) x 2 trays
Paper Feed System: Feed roller and friction pad
Paper Height Detection: 4 steps (100%, 70%, 30%, Near end)
Power Source:
 24 Vdc and 5Vdc (from the copier/printer):
 120 Vac (120 V version) from the copier/printer when the
optional tray heater is installed
 220 – 240 Vac (230 V version) from the copier/printer when
the optional tray heater is installed
Max:
30 W (Copying/printing) 23 W (Optional Tray
Heater On)
Power Consumption:
Average:
17 W (Copying/printing) 15 W (Optional Tray
Heater On)
Weight: 25 kg (55 lb)
Size (W x D x H): 550 mm x 520 mm x 271 mm
One-Bin Tray
Paper Size:
Width: 140 ~ 297 mm
Length: 140 ~ 432 mm
Output Standard Position: Center
Paper Weight: 60 ~ 105 g/m², 16 ~ 28 lb
Tray Capacity: 100 sheets (A4 LEF 80 g/m
2
, 20 lb)
Power Source: 5 VDC, 24 VDC (from the copier)
Power Consumption: Max. 20 W
Weight: 1.55 kg (Base unit: 1.1 kg, Tray: 0.45 kg)
Size (W x D x H):
461 mm x 478 mm x 104 mm
(508 mm x 478 mm x 104 mm when tray extended)
