B245/B276/B277/B268/B269 Service Manual 18-Jan-06
82
Toner Supply Motor
1. Copy tray (
p.55)
2. Open the front door.
3. Toner bottle holder (
p.76)
4. Toner supply motor [A] (
x 1)
