Ricoh K-C3 - Installing Panels and Keys

B245/B276/B277/B268/B269 Service Manual 18-Jan-06
36
Tray Heaters For The Optional Paper Feed Units
1. Remove the rear cover [A].for the paper tray unit
One-tray paper
feed unit:
Two-tray paper
feed unit:
2. Two-tray unit only: Remove the cable guide [B].
3. Install the clamps [C].
