Ricoh K-C3 - Other Component Replacements

B245/B276/B277/B268/B269 Service Manual 18-Jan-06
95
Fusing
Fusing Unit
 The fusing unit can become very hot. Make sure that it has cooled down
sufficiently before you handle it.
1. Turn off the main switch, and unplug the machine.
2. Front right cover
3. Open the right door.
4. Fusing unit [A] (
x 2, x 4)
Thermistor
1. Fusing unit (see above)
2. Thermistors [A] (
x 1, x 1)
