B245/B276/B277/B268/B269 Service Manual 18-Jan-06
190
Code
130 Paper does not reach the one-bin tray.
131 Paper is caught at the one-bin tray.
SMC Print (SP 5990)
SP 5990 outputs machine status lists.
1. Select SP 5990.
2. Select a menu:
 Basic machine: 001 All, 002 SP, 003 UP, 004 Log, or 005 Big Font
 GDI machine: 001 All (Data List), 002 SP (Mode Data List), 003 User Program, 004
Logging Data, 005 Diagnostic Report, 006 Non-Default, 007 NIB Summary, 008 Net
File Log, 021 Copier User Program, 022 Scanner SP, 023 Scanner User Program,
040 Parts Alarm Counter Print, 064 Normal Count Print, 065 User Code Counter,
066 Key Operator Counter, 067 Contact List Print, 069 Heading1 print, 071
Heading3 print, 072 Group List Print, 128 ACC Pattern, 129 User Color Pattern, or
160:ACC Pattern Scan
 The output given by the menu "Big Font" is suitable for faxing.
3. Press the "Execute" key.
 Basic machine: The copy mode is activated
 Specify copy settings and press the key. The machine status lists is output.
 GDI machine: The machine status list is output.
4. To return to the SP mode, press the
key.
Original Jam History Display (SP 7508)
- Viewing the Copy Jam History -
You can view the information on the most recent 10 events. The information on older events
is deleted automatically.
 The information on jam history is saved in the NVRAM.
1. Select SP 7508.
2. Select one of the menu items ("Latest 1" through Latest 10").
3. Press the OK key. The summary of the jam history shows.
4. To view more information, select "Detail."
To Next Page
