Ricoh K-C3 - Service Tables; Service Program Mode; Enter the Service Program Mode; How to Enter the SP Mode

B245/B276/B277/B268/B269 Service Manual 18-Jan-06
139
Service Tables
Service Program Mode
 Do not let the user access the SP mode. Only service representatives are allowed to
access the SP mode. The machine quality or its operation is NOT guaranteed if
persons other than service representatives accesses the SP mode.
How to Enter the SP Mode
The following two modes are available:
 SP Mode (Service Program Mode): The SP Mode includes the programs that are
necessary for standard maintenance work.
 SSP Mode (Special SP Mode): The SSP Mode includes SP-Mode programs and some
special programs. You need some extra knowledge to manipulate these special
programs. For details, consult your supervisor.
Starting SP Mode
1. Type the keys as follows: [Clear Modes] > [1] > [0] > [7]
2. Press the [Clear/Stop] key and hold it down until the SP-mode menu is
displayed (about 3 seconds).
Starting SSP Mode
For the basic machine (the machine without the optional controller box), perform as listed in
steps 1 through 4. For the GDI machine (the machine with the optional controller box),
perform as listed in steps 1 through 5.
1. Type the keys as follows: [Clear Modes] > [1] > [0] > [7]
2. Press the
key and hold it down until the SP-mode menu shows (about 3
seconds).
3. Press the [Enter] key and hold it down.
