B245/B276/B277/B268/B269 Service Manual 18-Jan-06
104
Other Replacements
Quenching Lamp
1. PCU (
p.76 )
2. Quenching lamp [A] (
x 1)
High-Voltage Power Supply Board
1. Rear cover ( p.54)
2. High-voltage power supply board [A] (
x 2, 3 standoffs, all connectors)
