B245/B276/B277/B268/B269 Service Manual 18-Jan-06
263
Energy Saver Modes of Basic Machines
This section illustrates the energy saver modes of the basic machine (the machine without
the optional controller). For the energy saver modes of the GDI machine (the machine with
the optional controller), see the section of "Energy Saver Modes of GDI Machines".
Overview
The machine has two energy-saver modes: the Low Power Mode and the Night/Off Mode.
The table lists the status of several components. For the fusing temperature, see the section
of "Fusing Temperature Control".
Operation panel Engine Exhaust fan
Operating Mode
*
On On On
Low Power Mode Off On Off
Night/Off Mode Off Off
**
Off
*
The "Operating Mode" here refers to all the modes (and status) other than the Low Power
Mode and Night/Off Mode. Actual power consumption (during the Operating Mode) depends
on job status and environmental conditions.
**
The SRAM is alive and backs up the engine controller.
