Ricoh K-C3 - Registration Clutch; Registration Sensor

B245/B276/B277/B268/B269 Service Manual 18-Jan-06
89
Registration Clutch
1. Rear cover (
p.54)
2. High-voltage power supply board (with the bracket) [A] (
x 4, all connectors)
3. Registration clutch [B] (
x 1, x 1)
Registration Sensor
1. Open the right door.
2. Registration sensor [A] (
x 1)
