Ricoh K-C3 - One-Tray Paper Tray Unit

B245/B276/B277/B268/B269 Service Manual 18-Jan-06
279
 Max. length 1,260 mm
 Min. length 128 mm
Original Weight: 52 – 105 g/m
2
(14 – 28 lb)
Table Capacity: 30 sheets (80 g/m
2
, 22 lb)
Original Standard Position: Center
Separation: FRR
Original Transport: Roller transport
Original Feed Order: From the top original
Reproduction Range: 50 – 200%
Power Source: 24 and 5 Vdc (from the main frame)
Power Consumption: 25 W
Dimensions (W x D x H): 550 mm x 470 mm x 90 mm
Weight: Not above 7 kg (15 lb)
One-Tray Paper Tray Unit
Paper Size A5 to A3, 5
1
/
2
" x 8
1
/
2
" SEF to 11" x 17"
Paper Weight: 60 – 105 g/m
2
, 16 – 28 lb
Tray Capacity: 500 sheets (80 g/m
2
, 20 lb ) x 1 tray
Paper Feed System: Feed roller and friction pad
Paper Height Detection: 4 steps (100%, 70%, 30%, Near end)
Power Source:
 24 Vdc and 5Vdc (from the copier/printer):
 120 Vac (120 V version) from the copier/printer when the
optional tray heater is installed
 220 – 240 Vac (230 V version) from the copier/printer when
the optional tray heater is installed
Max:
20 W (Copying/printing) 23 W (Optional Tray
Heater On)
Power Consumption:
Average:
13 W (Copying/printing) 15 W (Optional Tray
Heater On)
Weight: 12 kg (26.4 lb)
Size (W x D x H): 550 mm x 520 mm x 134 mm
