B245/B276/B277/B268/B269 Service Manual 18-Jan-06
265
Energy Saver Modes of GDI Machines
This section illustrates the energy saver modes of the GDI machine (the machine with the
optional controller). For the energy saver modes of the basic machine (the machine without
the optional controller), see the section of "Energy Saver Modes of Basic Machines".
Overview
The machine has three energy-saver modes: the Low Power Mode, the Transit Mode, and
the Night/Off Mode. The Transit Mode continues for about two seconds (probably, the user
does not recognize this mode when it occurs). The table lists the status of several
components. For the fusing temperature, see the section of "Fusing Temperature Control".
Operation panel Engine Exhaust fan
Operating Mode* On On On
Low Power Mode Off On Off
Transit Mode Off On Off
Night/Off Mode Off Off** Off
*
The "Operating Mode" here refers to all the modes (or status) other than the Low Power
