B245/B276/B277/B268/B269 Service Manual 18-Jan-06
160
6006*
ADF Adjustment (
p.114
NOTE: Available menus depend on the machine model and its configuration.
ADF Adjustment (StoS/Front Regist)
[–5.0 ~ +5.0 / 0.0 / 0.1 mm/step]
6006 1
Adjusts the side-to-side registration for the front side of the original, for ADF
mode. Use the
key to select “+” or “–” before entering the value
ADF Adjustment (Leading Regist)
[–5.0 ~ +5.0 / 0.0 / 0.1 mm/step]
6006 2
Adjusts the leading edge registration for ADF mode. Use the
key to select
“+” or “–” before entering the value.
ADF Adjustment (Trailing Erase)
[–3.0 ~ +3.0 / –1.0 / 0.1 mm/step]
6006 3
Adjusts the trailing edge erase margin for ADF mode. Use the
key to select
“+” or “–” before entering the value.
ADF Adjustment (StoS/Rear Regist)
[–5.0 ~ +5.0 / 0.0 / 0.5 mm/step]
6006 4
Adjusts the side-to-side registration for the rear side of duplex originals, for ADF
mode. Use the
key to select “+” or “–” before entering the value.
ADF Adjustment (Sub-scan Magnif)
[–0.9 ~ +0.9 / 0.0 / 0.1 %/step]
6006 5
Adjust the sub-scan magnification for the ADF.
ADF Adjustment (Original Curl Adj)
[0 = No / 1 = Yes]
6006 6
Enables or disables the skew adjustment for the reverse sides of originals.
When you enable SP6-006-6, adjust the distance of the skew adjustment (SP
6006 7).
ADF Adjustment (Skew Correction)
[–20 ~ +20 / 0 / 1 mm/step]
6006 7
Specifies the distance of the skew adjustment. SP 6006 7 is effective when you
enable SP 6006 6 (ADF Adjustment [Original Curl Adj]).
6009
ADF Free Run
6009 1 Performs an ADF free run. Press "ON" to start; press "OFF" to stop.
6010
Stamp Position Adjustment
[–10 ~ +10 / 0 / 1 mm/step]
6010 1 Adjusts the stamp position in the sub-scan direction. for the fax mode.
6901
Display ADF/APS
6901 1
Displays the status of the ADF original size sensors (
p.191).
6910*
ADF Shading Time
[0 ~ 60 / 10 / 1 s/step]
