B245/B276/B277/B268/B269 Service Manual 18-Jan-06
177
4. The sign "01H" or "00H" show (see the table below).
- Input Check Table -
Num. Sensor/Switch 01H 00H
001 Safety SW Open Closed
002 Safety SW-LD 5V Open Closed
003 Right Cover SW Open Closed
004 Right Low Cover SW Open Closed
005 Tray Cover SW Open Closed
006 Upper Relay S Paper detected Not detected
007 Lower Relay S Paper detected Not detected
008 Vertical Trans S Paper detected Not detected
009 Registration Sensor Paper detected Not detected
010 Exit Sensor Paper detected Not detected
011 Duplex Inverter S Paper detected Not detected
012 Duplex Entrance S Paper detected Not detected
013 Duplex Exit S Paper detected Not detected
014 By-pass PE S Paper detected Not detected
015 By-pass P Size S *1
016 Upper PE S Paper detected Not detected
017 Lower PE S Paper detected Not detected
018 Upper P Size SW *1
019 Lower P Size SW *1
020 BK-Upper Paper End S Paper detected Not detected
021 BK-Lower Paper End S Paper detected Not detected
022 BK-Up P Size SW *1
023 BK-Low P Size SW *1
024 BK-Up P Height S *2
025 BK-Low P Height S *2
026 BK-Upper Lift S At upper limit Not at upper limit
028 BK type *3
030 Duplex Installed Installed Not installed
031 Lower Lift S At upper limit Not at upper limit
032 Main M Lock Locked Not locked
033 Polygon M Lock Locked Not locked
