B245/B276/B277/B268/B269 Service Manual 18-Jan-06
268
Europe, Asia: 220 – 240 V, 50/60 Hz, 7 A
Full System: Not above 1.28 kW
Off Mode (GDI): Not above 10 W
Off Mode (Basic): Not above 1 W
Power Consumption:
Full system - Maximum possible power consumption
(any combination of mainframe and options), excluding
optional heaters, key counter, fax unit, and printer
controller.
Standby (Mainframe/Full system): Not above 40 dB(A)
Operating (Mainframe only): Not above 62 dB(A)
Operating (Full System): Not above 66 dB(A)
Noise Emission:
The above measurements were made in accordance
with ISO 7779. Measurements were taken from the
normal position of the operator.
Dimensions (W x D x H):
B245/B276/B268: 550 x 568 x 420 mm (21.7" x 22.4" x 16.5")
B269/B277: 587 x 568 x 558 mm (23.1" x 22.4" x 23.0")
Measurement Conditions
1. With bypass feed table closed
2. Without the A(R)DF
Weight:
B245: 35 kg (78 lb.)
B268/B276: 44 kg (96 lb.)
B269/B277: 47 kg (103 lb.)
(Excluding A(R)DF, platen cover, toner, and developer)
Copying Speed in Multicopy Mode (copies/minute):
Mode B245 B276 B277
A3 SEF/11" 17" 9 10 11 1-sided
1-sided
Memory copy
A4 LEF/11" x 8
1
/
2
" 15 16 20
A3 SEF/11" 17" 8 8 8
A4
LEF/11"
x 8
1
/
2
"
DF 1-to-1
15 16 18
