Zones Cross Zones
Quick keys Parameter Default Range
Cross Zones None
1. From the installer Programming menu, press . The following
appears:
ZONES CROSSING:
01) 001 S 001
2. You are at the first set of zone links(01) – or scroll to go to the next set
of zone links (50 sets maximum) ; the following displays:
CROSSING SET 01:
1ST = 001 2ND=001
3. Select the zone sets manually, as required, by making changes to the
number of the first zone in the set, followed by the number of the
second zone. If necessary, toggle between all the possibilities for each
digit (you can also scroll to them).
Note
Zones crossed with themselves are valid pairs. They need to register a
violation twice to trigger the alarm. This process is known as Double
Knock.
4. Press OK to display the correlation type screen where you select how
the system will process violations of the paired zones:
NONE– Not correlated: Temporarily disables any associated zone
pairings
ORDERED–Correlated: Effects an alarm so the first listed zone is
tripped before the second
NOT ORDERED–Correlated: Affects an alarm in which either zone
in the pair may be tripped first. In this case, the specified zone order
(1st, 2nd) has no bearing on the alarm activation.
5. Press OK
to display the alarm violation differential screen:
T.SLOT: XXX,YYY
SIZE=1 MINUTES
6. Enter the time slot, meaning the maximum amount of time allowed
between the triggering events for them to be considered a valid
violation (XXX, YYY indicate the crossed zones).
Default: 1 min
Range: 1 to 9 minutes
7. Repeat the entire process, as required, for any additional zone links
(up to 50).
