11
2017 Page 197 5IN2413 B
Quick Keys Parameter Default Range
3. Press OK again to advance to the next communication module/bus
device found, and again enable/configure for all the remaining ones
found. When BUS Device 1) Automatic displays again at the keypad
and the panel beeps,
it indicates you’ve finished going through all the recognized
modules/devices.
NOTE: Verify that all the system-connected modules and devices
display in the results, and that they all have all been enabled.
4. Now you can perform a Bus Test to ensure good communication
between the bus devices and the main panel (see
Performing a Bus
Test, page 54
).
Describing Auto-Setting Results
At the keypad, the results of a bus scan first show the connected
communication modules. The next results displayed are for connected
keypads, expansion/voice modules and bus detectors. Results display as
per this example: (3:02:01) T=LCD
EXPLANATION:
NOTE: Dashes (“—“) appear instead of digits when a parameter is not
relevant, for example, for communication modules as they are on-board
the PCB, and not on a bus line.
• 3 is the bus line it is connected to
• 02 is the expander ID
• 01 is its sequential, installer-set physical ID number for bus devices
Note that communication modules will always appear as 01.
• T is the type, which, in this example is LCD
Wireless Devices
The following parameters can be defined for wireless devices:
• RX Calibration
• Allocation
• Delete
Note
Allocation of wireless devices can be performed only if a wireless expander module has
been defined in the system.
