Step 5: Connecting the Backup Battery and Mounting
the Main Panel
Install the backup battery and then mount the main panel on the wall.
Connecting the Backup Battery
The main panel’s backup battery is not supplied with the system. You will need to
install a rechargeable battery (12 V, 18 Ah), which is automatically utilized as a
backup in case of power failure.
WARNINGS:
• To prevent damage, do not connect the backup battery until completion of all
installation tasks, and until the system is ready for initial power-up.
• Install battery with the correct polarity.
• There is a risk of explosion if a battery is replaced with an incorrect type.
• Dispose of used batteries according to applicable law and regulation.
• The battery will take at least 24 hours before it can be fully used for backup.
• Replace backup battery about every 3—5 years. No maintenance is needed.
 To connect the backup battery:
1. First ensure DIP switches and jumpers are set correctly in order to program
system parameters (see Setting Main Panel DIP Switches and Jumpers, page 27).
a. At SW1 on the main panel PCB, set DIP switch 2 to ON. This allows
language selection at first-time system power-up.
b. To bypass unused box and bell tampers (prevents tamper alarms), at SW1
set box tamper and bell tamper DIP switches (4 and 5 respectively) to ON.
c. You can configure battery discharge protection with the Non Protect
jumper (see Main Panel Jumper Setting, page 28).
2. Now connect the leads of the battery cable to the respective (+) and (—)
terminals on the battery and ensure correct polarity.
3. Insert the backup battery into its place in the main panel box/enclosure housing
(see the instructions packaged with the box/enclosure).
4. Connect the battery cable onto the Battery connector on the main panel PCB.
Mounting the Main Panel
 To mount the main panel:
• Close up the box/enclosure and mount it to the wall (see the box/enclosure
installation instructions), and see Step 1: Creating a Plan for Mounting the System,
page 23. You are now ready for initial system power-up and initialization.
