Defining APN Automatically and Manually
After the SIM card is installed and upon establishing GSM/GPRS communication,
the system’s auto-APN feature will automatically configure the APN definitions.
However, there may be cases where you will need to manually define the APN by
entering the APN (Access Point Name) code supplied from the cellular provider,
user name, and password.
NOTE: If any of the APN definition fields are populated manually, the auto-APN
feature will not operate.
 To manually set the APN definitions:
1. From the installer Programming menu, select: 5  1  2  2  1
(Communication  Method  GSM  GPRS  APN code), and then press
OK ( ).
2. Enter the APN code, and then press OK.
3. Scroll to 2) APN User Name, press OK, enter the user name, then press OK.
4. Scroll to 3) APN Password, press OK, enter the password, and then press OK.
IP Modules
1. From the installer Programming menu select 71 2, scroll to 11) IP, and then
press OK ( ).
2. Toggle to the type of IP module installed (or select NONE to cancel its
allocation), and then press OK.
Setting Dynamic IP / Static IP
To set IP communication to Dynamic IP or Static IP, go to: 5  1  3  1  1,
scroll to either 1) Dynamic IP or 2) Static IP, and then press OK ( ).
PSTN Modem Module
1. From the installer Programming menu select 7 1 2, scroll to 12) Modem,
and then press OK ().
2. Toggle to Modm (or select NONE to cancel its selection), and then press OK.
Long-Range Radio Transmitter Module
See the LRT instructions.
1. From the installer Programming menu select 71 2, scroll to 14) LRT, and
then press OK ().
2. Toggle to the type of LRT module installed (or select NONE to cancel its
allocation), and then press OK.
