Step 5: Basic Zone Configuration for All Zone Types
Defining Basic Parameters
You can define basic parameters for all types of zones. The relevant parameters
display dynamically according to the respective zone type.
You can define all the various zone parameters for one zone at a time by using the
“One By One” option, or you can take a specific parameter and define it
accordingly for multiple zones by using the “By Category” option. Also you may
need to define the zone’s termination resistance (“Resistance” option) if using
relay detectors and zone expanders.
After defining the basic zone parameters, you can define advanced parameters for
bus zones and wireless zones (see Step 6: Advanced Zone Configuration for Bus Zones
and Wireless Zones, page 68).
Describing Zone Information Displayed at the Keypad
At the keypad you will be entering the zone information which will be displayed
as per this example: Z=125 (1:E03:06):
EXPLANATION:
• Z=125 is the zone’s index number (up to 512 zones possible)
• 1 is the RISCO bus line number (1—4)
• E03 is the expansion module ID (shows as E00 if wired at the
terminal block)
• 06 is the zone’s installer-set physical (and sequential) ID number
Defining Zone Parameters using the “One-By-One” Option
This option lets you to define all zone parameters, for one zone at a time.
To define zone parameters using the One-By-One option:
1. From the installer Programming menu go to: 2 1 1 (Zones Parameters
One by One); the first zone (Z=001) displays in the format described above.
2. Using the numeric keys, you can change the zone’s 3-digit zone number to the
one for which you want to define its parameters, and then press OK ().
3. You can now define the following parameters for this specific zone (moving
from one parameter type to another by pressing OK):
