Risco ProSYS Plus - Replacing the Main Panel PCB; Setting Main Panel DIP Switches and Jumpers; Main Panel DIP Switch Settings

11
/
2017 Page 27 5IN2413 B
4. [For PSTN only]: At the terminal block on the main panel PCB, connect the
telephone line to the Line terminals (or PLUG10 jack) and connect the
telephone unit to the Set terminals (or PLUG9 jack). See Main Panel Wiring
Diagram, page 25.
5. Ensure correct ground wiring as follows:
a. At the center (ground) fuse terminals shown above, ensure that one center
terminal is wired to the box / enclosure. Then wire the power cable’s
ground wire to the other center terminal.
b. A ground wire connects between the box/enclosure and its cover. Refer to
the box/enclosure instructions for details.
Replacing the Main Panel PCB
If replacing the main panel PCB, in order to prevent bus sirens from sounding,
before you power-off the main panel first enter the installer Programming mode.
Then you can power-off the main panel and replace the PCB assembly.
Setting Main Panel DIP Switches and Jumpers
Main Panel DIP Switch Settings
Set the following DIP switches at the main panel PCB (SW1) as required:
DIP switch (SW1) State / Description
1: Bell
ON (Default): Bell: For a bell or electronic siren with a built-in siren
driver.
OFF: For a loudspeaker without a built-in sound driver.
2: Default
ON: Intended for installer programming at initial system setup (from
the installer Programming menu), this setting allows the installer
to use the keypad before it’s allocated. Caution: If set to ON any
time after exiting the installer Programming menu, it will reset
installer, sub-installer and Grand Master codes to factory
defaults.
OFF (Default): For after exiting installer Programming menu – such as
during installer programming from other installer menus (other
than Programming menu), and during regular system operation.
3: Program
OFF (default). NOTE: Not to be set by installer— factory use only.
4: Box tamper
bypass
ON: Box tamper protection is bypassed (not active)
OFF (Default): Box tamper protection is not bypassed (active)
5: Bell tamper
bypass
ON: Bell tamper protection is bypassed (not active)
OFF (Default): Bell tamper protection is not bypassed (active)
