Outputs
The Utility Output menu provides access to the following submenus and their
related programming parameters that enable you to choose among the following
event types that will trigger a selected Utility Output, as well as the manner in
which the output will be applied:
• Nothing
• System
• Partition
• Zone
• Code
Nothing
This parameter is for disabling a previously enabled utility output.
Note
When selecting output utility output number (1—10), if the UO number appears with a 0
first (for example 0xx, whereas xx is the UO number) that indicates the UO is connected
directly to the terminal block and not assigned to an output expander.
1. From the installer Programming menu go to 3)Outputs and then press
OK ( ).
2. Scroll to a UO number to disable (1—10), and press
OK.
3. Scroll to 0)Nothing and then press
OK.
4. Scroll to additional programmed outputs to disable, then press
OK after each.
Outputs Nothing
Quick keys Parameter Default Range
xx
Nothing
Disables a previously enabled programmable output
