Resistance
Define termination resistance for the wired zones. See Defining Zone Termination
Resistance, page 46 and also the Resistance parameters below:
Zones Parameters Resistance
Quick keys
Parameter Default Range
Resistance
You can define separately the end-of-line termination resistance of relay
zones and zone expanders.
1. Scroll to select the termination resistance value(s) for a wired zone
(relay detector, zone expander).
2. Press OK.
NOTE: When adding a zone expander (8- or 16-zone), define the
termination resistance compatibility for the zone expander itself,
according to the “highest” level of any relay detector you intend to
connect to it. For example, if you have EOL, DEOL and TEOL detectors
connected to the zone expander (or if you have only EOL and DEOL
detectors, but you want to leave open the possibility of adding a TEOL
detector to the zone expander in the future), you’ll need to set the zone
expander’s termination resistance values to TEOL – the “highest” level.
NOTE: For retrofit installations, define the resistance compatibility
according to the resistors already installed in the relay detectors.
Zone Termination Resistance Value in Ohms
EOL DEOL TEOL EOL DEOL EOL DEOL
00 Custom 05 3.74K 6.98K 10 3.3K 3.3K
01 2.2K
(default)
2.2K,
2.2K
(default)
06 2.7K 2.7K 11 5.6K 5.6K
02 4.7K 6.8K 4.7K,
6.8K,
12K,
(default)
07 4.7K 4.7K 12 2.2K 1.1K
03 6.8K 2.2K 08 3.3K 3.3K 13 2.2K 4.7K
04 10K 10K 09 1K 1K
