Partition
Define parameters that follow partition events.
Note
When selecting output utility output number (1—10), if the UO number appears with a 0
first (for example 0xx, whereas xx is the UO number) that indicates the UO is connected
directly to the terminal block and not assigned to an output expander.
1. From the installer Programming menu go to 3)Outputs and then press OK ().
2. Scroll to a UO (utility output) to configure (1—10), and press OK.
3. Scroll to 2)Partition and then press OK.
4. Scroll to a parameter to configure in the table below, and then press OK.
5. Select the partition/s by entering the numbers (you can enter a number again to
clear it), and then press OK.
6. Scroll to the pattern of operation option (see Pattern of Operation for Utility
Outputs, page 145), and then press OK.
7. Set other parameters as relevant (such as pulse duration and UO label), and
then press OK after each.
Outputs Partition
Quick Keys
Parameter
xx
Ready Follow
Activates the output when all selected partition(s) are in a "ready” state.
xx
Alarm Follow
Activates the output when an alarm occurs in the selected partition(s).
xx
Arm Follow
Activates the utility output when the selected partition(s) is armed in
either the full (Away) or partial (Stay) arming mode. The utility output
will be activated immediately, regardless of the exit delay time period.
xx
Burglary Follow
Activates the output when an intruder (intrusion) alarm occurs in the
selected partition(s).
xx
Fire Follow
Activates the utility output when a fire alarm is triggered in the
selected partition(s) from the keypads or a zone defined as Fire
.
