Step 4: Allocating Wireless Zones
Multiple 1-way and 2-way wireless detectors and accessories are connected to the
system via wireless expansion modules – each of which supports multiple wireless
zones, and is connected to a RISCO bus line or at the main panel PCB.
NOTE: To set additional parameters, see Installer Programming, page 77.
Allocating Wireless Expanders
Wireless expanders must be allocated before their respective wireless devices.
 To allocate wireless expanders:
1. From the installer Programming menu, go to 7  1  2  0  5 (Install 
Bus Device  Manual  WL Expander).
2. Scroll to, and then edit the WL expander’s physical ID number to match its DIP
switch settings (see Describing Installer-Set ID Numbers for Bus Devices, page 38).
3. Toggle to WM (to enable the Wireless Expander module) or NONE (to cancel its
allocation), and then press OK ().
4. Define whether to bypass the wireless expander box tamper by toggling
between Y (to bypass) and N (to not bypass), and then press OK.
Allocating Wireless Devices
Allocate each wireless transmitting device via keypad or CS – either by sending an
RF transmission, or enter the device’s 11-digit code (see sticker on device for code).
Allocating Wireless Devices via RF Transmission
 To allocate a wireless device via RF transmission:
1. From the installer Programming menu, go to 7  2  2  1  1
(Install  WL Device  Allocation By RF  Zone).
2. If you have multiple wireless receivers, scroll to the first one for which you wish
to allocate it’s wireless devices, and then press OK ( ); Each zone appears in
one of the following formats: “Select (—:———:——)” which indicates the
zone is available for allocating, or “Select (3:E02:06)” which, in this example,
indicates the zone has already been allocated.
NOTE: Allocating the same WL zone again will re-write (cancel) prior allocation.
3. Scroll to the zone number you want to allocate (or enter the zone number using
3 digits – for example enter 022 for zone 22), and then press OK; the wireless
expander is now in “learn” mode for the next 180 seconds.
4. Per the table below, within the remaining time, send an RF transmission from a
wireless device that you want to sync with the selected wireless expander. If
“write message not found” displays, it means the transmission was not received
and the device didn’t get allocated.
