System
Define parameters that follow system events.
Note
When selecting output utility output number (1—10), if the UO number appears with a 0
first (for example 0xx, whereas xx is the UO number) that indicates the UO is connected
directly to the terminal block and not assigned to an output expander.
1. From the installer Programming menu go to 3)Outputs and then press OK ( ).
2. Scroll to a UO number to configure (1—10), and press OK.
3. Scroll to 1)System and then press OK.
4. Scroll to a parameter to configure in the table below, and then press OK.
5. Scroll to the pattern of operation option (see Pattern of Operation for Utility
Outputs, page 145) and then press OK.
6. Set other parameters as relevant (such as pulse duration and UO label), and
then press OK after each.
Outputs System
Quick keys Parameter
xx
Bell Follow
Activates when a bell is triggered. If a bell delay was defined, the utility
output will be activated after the delay period.
xx
Communication Failure
Activates when communication with the monitoring station cannot be
established. Deactivates after a successful call is established with the MS.
xx
Trouble Follow
Activates when a system trouble condition is detected.
Deactivates after the trouble has been corrected
xx
Low Battery Follow
Activates when the ProSYS Plus panel’s rechargeable standby battery has
insufficient reserve capacity and the voltage decreases to 11 V or following
an accessory low battery indication.
xx
AC Loss Follow
Activates when the source of the main panel’s AC power is interrupted.
This activation will follow the delay time defined in the system control
times and the AC Off Delay Time parameter (see
AC Off Delay page 80).
