Appendix B: Wiring
The proper use of wire and cable is necessary for the successful installation and
operation of the ProSYS Plus system. It is important to select wire of the correct
attributes to minimize power loss and ensure reliable system operation. Take into
account both the installation's current requirements (for this you can utilize the
HandyApp calculator feature) and the wiring distances involved. The following
tables provide useful information:
Resistance per AWG Size and Distance
AWG Gauge
Size
Wire Diameter Resistance: Meters Resistance: Feet
Millimeters Inches Ω Per
Meter
Ω Per
100 Meters
Ω Per Foot Ω Per
1000 Feet
24 0.50 0.020 0.085 8.5 0.026 26.0
22 0.64 0.025 0.052 5.2 0.016 16.0
20 0.80 0.031 0.032 3.2 0.010 10.0
19 0.90 0.035 0.026 2.6 0.008 8.0
18 1.00 0.040 0.020 2.0 0.006 6.0
16 1.27 0.050 0.013 1.3 0.004 4.0
14 1.63 0.064 0.008 0.82 0.0025 2.5
Wiring Distance between Panel and Plug-In Transformer
One-Way Wire Distance Between
ProSYS Plus main panel and
Plug-In Transformer
AWG (American Wire Gauge)
For best results use the indicated wire size or larger
(numerically lower) size
In Meters In Feet 22 20 18 16 14
Up to 5 Up to 15
4
5 - 8 15 - 25
4
8 - 12 25 - 40
4
12 - 20 40 - 60
4
20 - 30 60 - 100
4
Maximum Combined Length of all Expansion Bus Wiring
Wire Gauge Max Combined Length of ALL Expansion Bus Wiring
24 AWG 7/02mm 150 meters 492 feet
22 AWG 16/02mm 200 meters 656 feet
20 AWG 24/02mm 333 meters 1092 feet
19 AWG 28/02mm 400 meters 1312 feet
