11
2017 Page 208 5IN2413 B
Exit
When exiting installer Programming menu, go to 0) Exit and then press OK ().
Note that if exiting after programming in the installer Programming menu the very
first time (at initial system configuration), perform the following procedure:
Exiting Installer Programming Menu
Exiting Installer Programming Menu after Initial System
Programming
IMPORTANT: After you have finished programming all relevant parameters in
the installer Programming menu the first time – at the time of initial system
setup, you must then perform the following procedure to exit the installer
Programming mode. Afterwards you can then program additional parameters as
needed from the same menu, or from other installer menus.
To exit installer Programming menu after initial system programming:
WARNING: In the main panel box/enclosure do not touch any AC electrical
wiring to/from the mains fuse terminals nor the mains fuse terminals, as coming
into contact with 230 VAC can result in electric shock and death.
1. With the main panel still powered up, carefully open the main panel
box/enclosure.
2. At SW1 on the PCB, carefully set DIP switch 2 to OFF.
3. Close the main panel box/enclosure in order to prevent a front tamper alarm.
4. At the keypad, press Exit ( ) repeatedly to return to the start of the current
menu.
5. Press 0 to exit, toggle to Y to save all your programming settings, and then press
OK ( ); TAMPER TESTING displays as the system checks for tamper trouble
conditions.
6. If an alarm sounds and you want to quit with a current tamper trouble
condition, press Exit, then toggle to Y (yes), and then press OK.
NOTE: If you select N (no), you will not be able to exit installer Programming
mode until the tamper trouble condition has been restored to normal.
