11
/
2017 Page 196 5IN2413 B
Install Bus Devices Testing
Quick Keys Parameter Default Range

Testing
The Testing menu enables performing a bus scan and a manual “Auto
Setting” bus scan of the system.

Bus Test
A Bus Test checks each installed bus device and communication module to
ensure adequate connectivity quality.
A result of 97% or less than may mean that there are bus connection
problems.
To perform a Bus Test:
1. From the installer Programming menu, go to: 7 1 3 1 (Install
Bus Device Testing Bus Test); BUS TEST displays for a few
seconds until the “BUS COM QUALITY” results display.
2. Scroll to view the results for each bus device/module on the tested bus
.
If a result is not adequate, check physical connections and DIP switch
positions, and then repeat the test. Results display as per this example:
GSM :001=100%
EXPLANATION:
GSM is the bus device/communication module description
001 is the bus device/communication modul
e index number
100% is the result
Install Bus Devices Testing Bus Scan (Auto Setting)
Quick Keys Parameter Default Range

Bus Scan (Auto Setting)
The Bus Scan is the same as the Auto Setting scan that is run at initial
system start-up. The Bus Scan is typically used, for example, after
manually allocating devices.
To perform a bus scan:
1. Press OK ( ); BUS SCANNING displays during the scan, then the
results display (the connected communication modules and bus
devices that were found).
2. Press OK to enable the first communication module/bus device
displayed, and keep pressing OK to progress through its parameter
configuration screens (which you can configure now or later during
installer programming).
