Communication Method Radio (LRT)
Quick Keys Parameter Default Range
LRT (Long-Range Radio Transmission)
The LRT menu contains parameters for setting a system long-range radio
communication network, using the Location Aided Routing (LARS) protocol
(LARS, LARS1, or LARS2) or E-LINE protocol to facilitate detailed event
transmission to monitoring stations.
Account
0
0—00FFFF
The number that recognizes the customer at the monitoring station. You can
define an account number for each monitoring station. These account
numbers are the 6-digit numbers assigned by the monitoring station.
Notes
Account Number Communication Format:
• The account number will always be reported as 4 digits, for example: A
number defined as 000012 will be reported as 0012
• The account range depends on which protocol is in effect, as follows:
Protocol Range
LARS 0000–7779 (First 3 digits: 0–7 only)
LARS1 0000–1FFF
LARS2 0000–FFFF
If more than 4 digits were defined, the system always sends the last 4
digits of the account number, for example: Account number that was
defined as 123456 will be sent as 3456.
System
0 LARS 0–3
LARS1 0–7
LARS2 0–F
Use the one-digit system code to efficiently allocate transmitter reporting
among monitoring stations.
Periodic Test
00 HR: 00–96
MIN 00–59
The Periodic Test enables you to set how often the system will automatically
establish communication to the monitoring station in order to confirm
operational functionality. The periodic test involves sending the account
number and a valid test report code (Contact ID 602).
