11
2017 Page 174 5IN2413 B
Quick Keys Parameter Default Range
MS Non Urgent
Reports non-urgent events (supervisory troubles and test reports) to
the monitoring station (MS):
Do not call (no report)
Call 1st: Reports Openings and Closings to MS 1.
Call 2nd: Reports Openings and Closings to MS 2.
Call 3rd: Reports Openings and Closings to MS 3.
Call all: Reports Openings and Closings to the all defined MS.
1st Backup 2nd: Reports Openings and Closings to MS 1. If
communication is not established, calls MS 2.
1st Backup 2nd 3rd: Reports to MS 1. If communication is not
established calls MS 2.
If communication is not established again calls the MS.
1st Backup 3rd Call 2nd: Reports MS 1. If communication is not
established calls to MS 3. In addition it will also call MS 2.
2nd Backup 3rd Call 1
st
: Reports to MS 2. If communication is not
established calls MS 3. In addition it will also call MS 1.
Communication Monitoring Station Report Codes
Quick Keys Parameter Default Range
Report Codes
Enables you to view or program the codes transmitted by the system to
report events (for example, alarms, troubles, restores, supervisory tests,
and so on) to the monitoring station.
The codes specified for each type of event transmission are a function
of the central station’s own policies. Before programming any codes, it
is important to check the central station protocols. Reporting codes are
assigned by default, according to the selected communication format
SIA or contact ID.
Assigns a specified report code for each event, based on the reporting
format to the monitoring station. An event that is not assigned with a
report code will not be reported to the monitoring station. For list of
report events see Monitoring Station Report Codes, page 235.
NOTE: Using a double-zero (00) for any event will prevent a report from
being generated.
