Fernsteuerbefehle
R&S
®
RTB2000
415Bedienhandbuch 1333.1611.03 ─ 05
BUS<b>:SSPI:CLOCk:SOURce.......................................................................................415
BUS<b>:SSPI:CLOCk:POLarity.......................................................................................415
BUS<b>:SSPI:DATA:SOURce.........................................................................................415
BUS<b>:SSPI:MOSI:SOURce.........................................................................................415
BUS<b>:SSPI:MISO:SOURce.........................................................................................416
BUS<b>:SSPI:DATA:POLarity......................................................................................... 416
BUS<b>:SSPI:MOSI:POLarity.........................................................................................416
BUS<b>:SSPI:MISO:POLarity.........................................................................................416
BUS<b>:SSPI:BITime.....................................................................................................417
BUS<b>:SSPI:BORDer...................................................................................................417
BUS<b>:SSPI:SSIZe......................................................................................................417
BUS<b>:SSPI:CLOCk:SOURce <Source>
Selects the input channel of the clock line.
Suffix:
<b>
.
1 | 2
Parameter:
<Source> CH1 | CH2 | CH3 | CH4 | D0..D15
CH3 and CH4 are only available with 4-channel R&S RTB2000
oscilloscopes.
*RST: CH1
BUS<b>:SSPI:CLOCk:POLarity <Polarity>
Selects if data is stored with the rising or falling slope of the clock. The slope marks the
begin of a new bit.
Suffix:
<b>
.
1 | 2
Parameter:
<Polarity> POSitive | NEGative
POSitive: rising slope
NEGative: falling slope
*RST: POSitive
BUS<b>:SSPI:DATA:SOURce <Source>
BUS<b>:SSPI:MOSI:SOURce <MosiSource>
Selects the input channel of the MOSI / MISO line.
Suffix:
<b>
.
1 | 2
Parameter:
<MosiSource> CH1 | CH2 | CH3 | CH4 | D0..D15
*RST: CH1
Analyse serieller Busse
