Fernsteuerbefehle
R&S
®
RTB2000
424Bedienhandbuch 1333.1611.03 ─ 05
BUS<b>:I2C:CLOCk:SOURce <Source>
Sets the input channel to which the clock line is connected.
Suffix:
<b>
.
1 | 2
Parameter:
<Source> CH1 | CH2 | CH3 | CH4 | D0..D15
CH3 and CH4 are only available with 4-channel R&S RTB2000
oscilloscopes.
*RST: CH1
BUS<b>:I2C:DATA:SOURce
<Source>
Sets the input channel to which the data line is connected.
Suffix:
<b>
.
1 | 2
Parameter:
<Source> CH1 | CH2 | CH3 | CH4 | D0..D15
CH3 and CH4 are only available with 4-channel R&S RTB2000
oscilloscopes.
*RST: CH1
15.11.3.2 I²C-Trigger
To configure the protocol trigger, make sure to set first:
●
TRIGger:A:TYPE to BUS
●
TRIGger:A:SOURce to SBUS1 | SBUS2
TRIGger:A:I2C:MODE.................................................................................................... 424
TRIGger:A:I2C:ACCess..................................................................................................425
TRIGger:A:I2C:AMODe.................................................................................................. 425
TRIGger:A:I2C:ADDRess................................................................................................426
TRIGger:A:I2C:PATTern..................................................................................................426
TRIGger:A:I2C:PLENgth.................................................................................................426
TRIGger:A:I2C:POFFset.................................................................................................427
TRIGger:A:I2C:MODE <Mode>
Specifies the trigger mode for I²C.
Analyse serieller Busse
