Reference
Modification no.
- 3 -
Page
265
Date
1999 01 01
Main
914 F
01480
Designation new wear limit actual dim.
mm (in.) mm (in.) int. / exh.
Sprag clutch
axial clearance 0 ................................... 0,30 ÷ 0,50 (0,012 ÷0,019) ............ 0,7 (0,028) ........................
Water pump
impeller clearance T .............................. 0,40 ÷ 0,50 (0,016 ÷0,019) ............ 0,7 (0,028) ........................
Oil pump
pump plunger, axial clearance 2 ............ 0,00 ÷ 0,07 (0,0 ÷0,028) ............ 0,2 (0,008) ........................
Ignition unit
spark plug, electrode gap Y ................... 0,6 ÷ 0,7 (0,024 ÷0,028) ............ 0,9 (0,035) ........................
gap 7 for "old type" trigger coil .............. 0,4 ÷ 0,5 (0,016 ÷0,020) ............ 0,5 (0,020) ........................
gap 7 for trigger coil with clamps........... 0,3 ÷ 0,4 (0,012 ÷0,016) ............ 0,4 (0,016) ........................
trigger coil, axial offsetting 8 ................. 0,0 ÷ 0,2 (0,000 ÷0,008) ............ 0,3 (0,012) ........................
Electric starter
armature, axial clearance 9 ................... 0,1 ÷ 0,2 (0,004 ÷0,008) ............ 0,3 (0,012) ........................
Push rod
out of round G ........................................ 0,0 ÷ 0,1 (0,0 ÷ 0,004) ............ 0,2 (0,008) ........................
