Rotax 914 F - Page 83

ReferenceModification no.
- 4 -
Page
83
Date
2002 01 01
Main
914 F
01476
Stud..................................turbo charger.............................M 8 .................... 6 Nm (55 in.lb)
Lock nut............................exhaust flange ..........................M 8 .................. 12 Nm (105 in.lb)
Clamp 120........................muffler ................................................................ 15 Nm (180 in.lb)
Hex. hd. screw .................fuel pressure control .................M 6 .................... 8 Nm (70 in.lb)
Hex. hd. screw .................external alternator (optional) .....M 10 ................ 40 Nm (350 in.lb)
Hex. hd. screw .................engine suspension frame..........M 10 ................ 35 Nm (310 in.lb)
Temperature sensor .........oil ..............................................M10x1 ............. 10 Nm (90 in.lb)
Temperature sensor .........airbox ........................................1/8-27 NPTF ... 20 Nm (180 in.lb)
Hose clamp ......................airbox........................................M 6 .................... 6 Nm (55 in.lb)
Hex. hd. screw .................carb flange ................................M 8 .................. 15 Nm (135 in.lb)
Clamp 60..........................carburetor..................................to 7 mm gap
oil filter..............................oil pump ....................................10 Nm(90 in.lb) plus 3/4 turn
Cap nut ............................ carburetor........................................................... 5,5Nm (49 in.lb)
Plug screw .......................fuel pressure regulator ......................................... 8 Nm (70 in.lb)
