7K • Chapter 9
9-2
Create a Setpoint
Loads a setpoint into the Scheduler program.
• You must enter all parameters required by this command. You may force
the scheduler to ignore the month, day, hour, or minute by entering the
wildcard code, 99, for that particular parameter.
• The Scheduler supports 100 setpoints numbered 00 through 99. You may
create up to 10 setpoints which execute at the same minute. If more than
one setpoint executes at the same minute, the setpoints will be executed
with the lowest numbered setpoint first, the next higher setpoint second,
and so on.
• If the controller loses main power, time-keeping will continue, however,
setpoints will not be executed, since the microprocessor will be down.
Setpoints missed during the power failure will not be executed when power
returns.
Command Form:
Command Form Data Digit
Create setpoint (PW) 28 (setpoint
number, macro,
month, day, hour,
minute) *
from table below.
(Use Day Code Table
for day parameter.)
Data Digits Explanation
00-99 setpoint number, two digits
xxxx macro, 4 digits
01-12 or 99 month, 2 digits or wildcard
01-68 or 99 day, 2 digits (see Day Code Table, page 9-3.)
00-23 or 99 hour, 2 digits or wildcard
00-59 or 99 minute, 2 digits or wildcard
