7K • Appendix D

D-10

Speech Synthesizer Module (SSM)

Parts: Speech Synthesizer Module (SSM)

Dated 05-05-89 Revised 04-08-91

Part # or Type Qty Location

Resistors

47¾ 5% 1/4W 3 R5, R10, R12

1K¾ 5% 1/4W 1 R11

1.2K¾ 5% 1/4W 1 R4

10K¾ 5% 1/4W 1 R1

20K¾ 5% 1/4W 3 R7, R8, R9

47K¾ 5% 1/4W 1 R2

100K¾ 5% 1/4W 1 R6

4.7K¾ 8-pin sip 1 RN1

4.7K¾ 10-pin sip 1 RN2

100K¾ 3/8" pot

1R3

Diodes

1N4002 2 D1, D2

ICTE-15/MPTE-15 1 D3

Capacitors

10pF ceramic NPO 1 C6

18pF ceramic NPO 1 C2

120pF ceramic NPO 1 C11

.0047µF film 1 C9

.039µF film 1 C10

.1µF MLC 9 C3, C4, C5, C13, C14, C15, C16, C17, C18

.47µF film 1 C8

1µF tantalum 1 C1

10µF tantalum 5 C7, C12, C19, C20, C24

22µF electrolytic 3 C21, C22, C23

Transistors

2N3904 1 Q1

Integrated Circuits

27C512 standard

vocabulary

1U5

27C512 expansion vocab 1 U6

74HC138 1 U4

74HC374 3 U7, U8, U9

LM7805 1 REG1

LM7906 1 REG2
