S-COM 7K - Command Quick Reference

Programming Tables
A-33
Command Quick Reference
Page Command Name Form and Data Digit Default User
4-1
Messages
4-11 Enable/Disable CW (PW) 63 01 x *
0 = OFF (disabled)
1 = ON (enabled)
ON
enabled
4-12 Select Frequency of CW (PW) 06 00 (tone code) *
See Tone Code Table on page A-20.
1500 Hz
4-13 Send Next CW Message Slowly (PW) 11 * normal rate
4-14 Select Normal CW Speed (PW) 12 x *
0 = 5 WPM 5 = 17 WPM
1 = 7 WPM 6 = 20 WPM
2 = 10 WPM 7 = 24 WPM
3 = 13 WPM 8 = 30 WPM
4 = 15 WPM 9 = 40 WPM
20 WPM
4-14 Select Slow CW Speed (PW) 13 x *
0 = 5 WPM 5 = 17 WPM
1 = 7 WPM 6 = 20 WPM
2 = 10 WPM 7 = 24 WPM
3 = 13 WPM 8 = 30 WPM
4 = 15 WPM 9 = 40 WPM
15 WPM
4-19 Select Frequency of Beep 48 (PW) 06 01 (tone code) *
See Tone Code Table on page A-20.
500 Hz
4-19 Select Frequency of Beep 49 (PW) 06 02 (tone code) *
See Tone Code Table on page A-20.
750 Hz
4-19 Select Frequency of Beep 50 (PW) 06 03 (tone code) *
See Tone Code Table on page A-20.
1000 Hz
4-19 Select Frequency of Beep 51 (PW) 06 04 (tone code) *
See Tone Code Table on page A-20.
1250 Hz
4-19 Select Frequency of Beep 52 (PW) 06 05 (tone code) *
See Tone Code Table on page A-20.
1500 Hz
4-19 Select Frequency of Beep 53 (PW) 06 06 (tone code) *
See Tone Code Table on page A-20.
1750 Hz
4-37 Select Courtesy Message (PW) 31 10 (message) * 60 mS
440 Hz
beep
(74 09)
4-37 Select Dropout Message (PW) 31 13 (message) * none
4-37 Select Pre-Timeout Message (PW) 31 16 (message) * TO in CW
4-37 Select Post-Timeout Message (PW) 31 19 (message) * TO in CW
4-37 Select Initial ID Message for Tx1 (PW) 31 30 (message) * ID in CW
4-37 Select Initial ID Message for Tx2 (PW) 31 33 (message) * 9983 ID
in CW
4-37 Select Normal ID Message for Tx1 (PW) 31 31 (message) * ID in CW
4-37 Select Normal ID Message for Tx2 (PW) 31 34 (message) * 9983 ID
in CW
