S-COM 7K - Send Initial ID Message

To Next Page

To Previous Page

7K • Chapter 12

12-8

Send Initial ID Message

Forces the identifier to send the Initial ID Message for TX1, along

with any ID Tail Message that may be selected.

Command Form:

Command Form

Send Initial ID Message for TX1 (PW) 55 *

Acknowledgment: Sends ID

Errors:

Error Meaning

? err 1 wrong number of digits entered

Default: None
