TS-32 Programming
Switch Number, 0 = Closed (ON) / 1 = Open (OFF)
# Freq Code 5 4 3 2 1
0 67.0 XZ 0 0 0 0 0
1 71.9 XA 0 0 0 0 1
2 74.4 WA 0 0 0 1 0
3 77.0 XB 0 0 0 1 1
4 79.7 SP 0 0 1 0 0
5 82.5 YZ 0 0 1 0 1
6 85.4 YA 0 0 1 1 0
7 88.5 YB 0 0 1 1 1
8 91.5 ZZ 0 1 0 0 0
9 94.8 ZA 0 1 0 0 1
10 97.4 ZB 0 1 0 1 0
11 100.0 1Z 0 1 0 1 1
12 103.5 1A 0 1 1 0 0
13 107.2 1B 0 1 1 0 1
14 110.9 2Z 0 1 1 1 0
15 114.8 2A 0 1 1 1 1
16 118.8 2B 1 0 0 0 0
17 123.0 3Z 1 0 0 0 1
18 127.3 3A 1 0 0 1 0
19 131.8 3B 1 0 0 1 1
20 136.5 4Z 1 0 1 0 0
21 141.3 4A 1 0 1 0 1
22 146.2 4B 1 0 1 1 0
23 151.4 5Z 1 0 1 1 1
24 156.7 5A 1 1 0 0 0
25 162.2 5B 1 1 0 0 1
26 167.9 6Z 1 1 0 1 1
27 173.8 6A 1 1 0 1 1
28 179.9 6B 1 1 1 0 0
29 186.2 7Z 1 1 1 0 1
30 192.8 7A 1 1 1 1 0
31 203.5 M1 1 1 1 1 1
