S-COM 7K - Select Path Access Mode

7K • Chapter 13
13-4
Select Path Access Mode
Selects one of 7 possible Access Modes for each receiver-to-
transmitter path.
• Enter the command to select the path to modify; replace the ‘x’ with one
digit, 0 through 6, from Patch Access Mode table below.
Command Form:
Command Form Data Digit
Select Rx1-to-Tx1 Access Mode (PW) 57 00 x * Path Access Mode
Table (below)
Select Rx2-to-Tx1 Access Mode (PW) 57 01 x * Path Access Mode
Table (below)
Select Rx3-to-Tx1 Access Mode (PW) 57 02 x * Path Access Mode
Table (below)
Select Rx1-to-Tx2 Access Mode (PW) 57 03 x * Path Access Mode
Table (below)
Select Rx2-to-Tx2 Access Mode (PW) 57 04 x * Path Access Mode
Table (below)
Select Rx3-to-Tx2 Access Mode (PW) 57 05 x * Path Access Mode
Table (below)
Path Access Modes:
Mode Access Explanation
0 No Access Activity on the COR and PL inputs is ignored.
1 Carrier Access (COR) Activity on the COR input will enable the path. Activity
on the PL input is ignored.
2 PL Access Activity on the PL input will enable the path. Activity on
the COR input is ignored.
3 COR-And-PL Access Activity on both the COR and PL inputs simultaneously
will enable the path.
4 COR-Or-PL Access Activity on either the COR or PL inputs will enable the
path.
5 COR–And-Anti-PL
Access
Activity on the COR input simultaneously with no activity
on the PL input will enable the path.
6 Always Access Activity on the COR and PL inputs is ignored. The path
is always enabled.
Acknowledgment: Sends OK
Errors:
Error Meaning
? err 1 wrong number of digits entered
? err 2 illegal digit entered
