Base Station Functions

19-3

Examples:

Dial the base station telephone number. When it answers, enter:

(PW) 63 13 1 *

This puts the controller into star/pound talkout mode. To exit the mode, enter:

(PW) 63 13 0 *.

Note: Be sure you have selected Base Station Mode with the Select Talkout

Transmitter Mode command on page 19-4.
