Progr
amming Tables
A-5
Beep Duration
Change Ch
aracters
Control Character 9910
Beep Duration Change
Code
10mS
70
20mS
71
30mS
72
40mS
73
60mS
74
80mS
75
120mS
76
160mS
77
240mS
78
320mS
79
Beep Gap Chan
ge Characters
Control Character 9910
Beep Gap Change
Code
10mS
60
20mS
61
30mS
62
40mS
63
60mS
64
80mS
65
120mS
66
160mS
67
240mS
68
320mS
69
304
306
Table of Contents
Default Chapter
5
Table of Contents
5
Selected Tables
13
Product Description
15
Standard Hardware Features
16
Configuration
16
Cabinet
16
Main Board
16
Optional Hardware Features
16
Telephone Interface Module
16
Speech Synthesis Module
16
Audio Delay Module
17
Standard Software Features
17
CW Identifier
17
CW Messages and Paging Formats
17
Timers
17
Repeater Characteristics
17
Clock and Calendar
18
Logic Inputs and Outputs
18
Command Language
18
Getting Started
19
Power on Initialization
19
Initialize Controller
19
Cold Start
20
Warm Start
20
Default Condition
20
Programming Fundamentals
21
Valid Digit and Time Detection
22
Control Command Structure
22
Example Control Command
23
Command Response Messages
24
Acknowledgment
24
Errors
24
Special Keys
25
Star (*) and Carrier Drop as Terminators
25
Pound (#) as Clear or Abort Key
25
DTMF Interdigit Timer
26
DTMF Mute Delay
26
Messages
27
Message Buffer
27
Message Handler
27
Control Characters
28
Routing and Unrouting Control Characters
29
Default
29
Examples
30
Synchronizing Messages and Commands
31
CW Messages
32
Control Character
32
Format
32
Pre-Message Delay Character
32
Wordspace Character
32
Frequency Change
32
Speed Change
33
CW Alphanumeric Characters
34
CW Punctuation and Related Characters
35
CW Frequency Change and Speed Change Characters
36
Command Enable/Disable CW
37
Command: Select Frequency of CW
38
Command: Send Next Message Slowly
39
Command: Select CW Speed
40
Beep Messages
42
Control Character
42
Format
42
Beep Parameters (General)
42
Pre-Message Delay Character
42
Factory-Fixed-Frequency Beeps
43
Owner-Fixed Frequency Beeps
44
Custom Beeps
47
Custom Beep Delay
47
Beep Gap Change Characters
47
Beep Duration Change Characters
48
Automatic Beep Gap on Character
48
Automatic Beep Gap off Character
49
Defaults
49
Single Tone Page Messages
49
Control Character
49
Format
49
Delays
49
Two-Tone Sequential Page Messages
50
Control Character
50
Format
50
Delays
50
Five/Six-Tone Page Messages
51
Control Character
51
Format
51
Delays
51
DTMF Page Messages
52
Control Character
52
Format
52
Delays
52
Defaults
52
DTMF Characters
53
DTMF Duration Change Characters
53
DTMF Custom Duration Change Characters
54
DTMF Gap Change Characters
54
DTMF Custom Gap Change Characters
54
DTMF Pause Characters
55
DTMF Custom Pause Characters
55
DTMF Custom Changes (Duration Gap Pause)
56
DTMF-Related Notes
56
DTMF Character Set Tables Explained
57
Examples
57
Synthesized Speech Messages
59
Control Character
59
Format
59
Delay Character
59
Pause Character
59
Timeout Timer
59
Synthesized Speech Vocabulary
59
Tone Codes
59
Tone Code Table Explained
60
Calculating Tone Codes
60
Run-Time Variables
61
Command: Select Programmable Messages
63
Command Send Message
68
Command: Select/Review Command Response Messages
70
Security
73
Command: Assign Control Operator Password
74
Command: Assign Master Password
75
Command: Enable/Disable Front Panel Display
78
Macros
79
Quantity of Macros
79
Size of Macros
79
Names of Macros
80
Contents of Macros
80
Sequence of Execution
81
Cautions
81
Applications of Macros
81
Command Create New Macro
83
Command Append to Macro
85
Command: List Macro in CW or Speech
87
Command Erase Macro
89
Command Erase All Macros
90
Command Rename Macro
91
Command Pause
93
Command: Select Power ON-Triggered Macro
94
Telephone Interface Functions
95
Autopatch
96
Accessing the Autopatch
96
Store-And-Forward Operation
96
Dumping the Autopatch
97
Autopatch Setup and Configuration
97
Autopatch Dialer
97
Autopatch Call Types
97
Examples
98
Autopatch Conversation Control
98
Autopatch Dialing Mode
99
Command: Select Autopatch Dialing Mode
100
Command: Enable/Disable Autopatch Dialing Mixed-Mode
104
Command: Select Pause ("B") Digit Time
105
Command: Enable/Disable Pound down (# Dump)
106
Command: Select Dialing Prefix
107
Command: Dump Autopatch Using a Code
109
Command: Select Autopatch Access- and Dump-Triggered Macro
110
Command: Enable/Disable Full-Duplex Mode
111
Command: Enable/Disable Autopatch Privacy
112
Command: Enable/Disable Repeater-To-Phone DTMF Mute
113
Command: Enable/Disable ID Messages During Autopatch
114
Command: Require Dump before Next Call
115
Command: Select Receiver-To-Autopatch-Triggered Macros
116
Command Landline Hookflash
117
Autopatch Timeout Timer
118
Command: Select Autopatch Timeout Timer
119
Command: Reset Autopatch Timeout Timer
120
Autopatch Access and Passwords
122
Command: Access Autopatch (with Password)
123
Autopatch Call Types
123
Command: Access Autopatch (Without Password)
124
Command: Change Autopatch Access Password
126
Command: Enable/Disable Autopatch Access Without Password
127
Command: Go Off-Hook
128
Autopatch Call Types
129
Command: Select Autopatch Call Types
130
Autopatch Restrictions
132
Uses of Autopatch Restrictions
132
Command: Clear (or Enter) Accepted Number Table
134
Command: Clear (or Enter) Rejected Number Table
136
Autopatch Redialer
138
Command Redial Last Number
139
Command: Clear Autopatch Redialer
140
Autopatch Call Counter
141
Command: Clear Autopatch Call Counter
142
Command: Send Autopatch Call Count
143
Phone Line Control Mode
144
Phone Line Busy Input
144
Phone Line Busy Output
144
Phone Line Answer Modes
144
Ring-In Delay
146
Ringout Limit
146
Command: Select Phone Line Answer Mode
147
Command: Select (Review) Phone Line Answer Message
148
Command: Select Phone Line Answer Macro
149
Command: Select Phone Line Off-Hook Timer
151
Command: Monitor/Talk out Via Phone
152
Reverse Patch
153
Command: Trigger Reverse Patch
154
Command: Answer Reverse Patch
155
Command: Select (Review) Reverse Patch Ringout Message
156
Command: Select Reverse Patch Ring-Triggered Macro
157
Multiple Port Access
158
Autopatch Audio Routing
159
Autopatch Command Response Message Routing
159
Receiver-Specific Autopatch Access
160
Preventing Multiple Accesses
160
Command: Select Receiver-Specific Access-Triggered Macros
161
Command: Select Command Response Message Routing
162
Clock and Calendar
163
Command: Set Clock and Calendar
164
Command: Adjust Daylight Savings Time
166
Command Reset Clock Seconds
168
Command: Adjust Clock Seconds
169
Scheduler
171
Command: Create Setpoint
172
Scheduler Day Code Table
173
Command: Delete One or more Setpoints
176
Command: Enable/Disable Scheduler
177
CTCSS Functions
179
Command: Enable/Disable CTCSS Encoder
180
Command: Select Frequency of CTCSS
181
DTMF Decoder
183
Command: Enable/Disable Command Response Messages
184
Command: Select DTMF Priority/Scan
185
Command: Select DTMF Decoder Interdigit Timer
189
Command: Select DTMF Decoder Mute Delay
190
Command: Enable/Disable DTMF Decoder Mute
191
Command: Enable/Disable DTMF Long Tones
192
Command: Select DTMF Long Tone Macros
193
Command: Select DTMF Digit-Decoded Macro
194
Identifier
195
Command: Select ID Message Interval
199
Command: Select ID Pending Interval
200
Command: Reset Initial ID Message to Normal
201
Command: Send Initial ID Message
202
Tail Messages
204
Command: Enable/Disable ID Messages During Autopatch
205
Links
207
Command: Enable/Disable Path
208
Logic Inputs
213
Command: Assign Macro to Logic Input
214
Logic Outputs
217
Command: Select Logic Outputs
218
Receiver Functions
219
Command: Select Receiver Activity-Triggered Macros
220
Command: Select Receiver Post-Activity Timers
220
Command: Select COR Pulse-Triggered Macro
222
Command: Select Pulse Parameters
222
Command: Enable/Disable End-Of-Transmission Command Execution
224
Command: Select From-Start-Of-Transmission Timer
226
Transmitter Functions
227
Transmitter Tail Sequence
227
Courtesy Delay and Courtesy Message
227
Dropout Delay and Dropout Message
227
Transmitter Timeout Timer and Timeout Message
227
Transmitter Unkey Delay
228
Command: Select Courtesy Delay
229
Command: Select Dropout Delay
230
Command: Select Transmitter Timeout Timer
231
Command: Reset Transmitter Timeout Timer
233
Command: Enable/Disable Transmitter
234
Command: Key Transmitter (Timed)
235
Command: Select Transmitter Minimum Unkey Delay
238
Command: Select Receiver-To-Transmitter-Triggered Macros
239
Command: Select Transmitter PTT-Triggered Macros
240
Repeater Functions
243
Command: Select Repeater Access Mode (Path 1)
244
Command: Select Repeater Activity-Triggered Macros
246
Command: Select Repeater Activity Counter/Timer
246
Command: Select Anti-Kerchunker Parameters
248
Command: Select Anti-Kerchunk no Hangtime Mode
250
Command: Select (Review) Courtesy Messages
251
Command: Select Repeater Action-Triggered Macros
253
Base Station Functions
255
Command: Enable/Disable Star/Pound Talkout
256
Command: Select Talkout Transmitter Mode
258
Command: Enable/Disable Command Execution on Interdigit Timer
259
User Timers
261
Command: Select Timeout Value
262
Command: Select Timer Event Macro
263
Command: Stop Timer
264
Command: Start Timer (Retriggerable)
265
Command: Start Timer (One-Shot)
266
Example: Fan Control
267
Example: an Activity Timer
268
Remote Base Interface
269
Remote Base Setup and Configuration
270
Wiring
270
Switch Setting
270
Software Configuration
270
Event-Triggered Macros
271
Command: Assign Remote Base Password
272
Command: Select Remote Base Access- and Dump-Triggered Macros
273
Command: Select (Review) Remote Base off Message
274
Command: Reset RBI-1
275
Command: Enable/Disable Access to the Remote Base
276
User Functions: Controlling the Radios
278
Defining Memory Channels Using Macros
279
User Function: Dump Remote Base
281
User Function: Speak Radio Configuration
282
User Function: Select Memory Channel and Band
284
User Function: Select VFO Frequency and Offset
285
User Function: Select Transmitter Offset
287
User Function: Enable/Disable Transmitter
288
User Function: Enable/Disable Receiver
289
User Function: Enable/Disable Radio Power
290
User Function: Select Transmitter Power Output
291
User Function: Select Frequency of CTCSS
292
TS-32 Programming Table
292
User Function: Enable/Disable CTCSS Encoder
293
User Function: Enable/Disable CTCSS Decoder
294
Macro Function: Send Queued Settings
295
RBI-1 User Function Outputs
296
Command: Select RBI-1 Number of User Function Outputs
297
Programming Tables
301
CW Character Set Tables
302
Beep Character Set Tables
304
DTMF Character Set Tables
307
Synthesized Speech Vocabulary (Male
310
Synthesized Speech Vocabulary (Female and Sound Effects
315
Message Run-Time Variables
316
Message Control Characters
317
Scheduler Day Code Table
318
Tone Code Table
319
Root Numbers (Commands) by Number
322
Event Macros by Number
324
Messages by Number
327
Tenth-Second Timers by Number
329
Tenth-Minute Timers by Number
329
Path Access Mode by Number
329
Software Switches by Number
330
Command Quick Reference
332
CW Speed
333
Application Notes
355
Using the 7K as a Beacon Controller
355
Positive Voltage TX Keying Circuit
357
Installation
359
Theory of Operation
359
Pre-Programming
359
Default Information
359
Power Supply
359
Repeater Interfacing
360
Control Receiver Interfacing
360
External Device Interfacing
360
Audio Gating
360
Tone Generation
360
Memory Protection
361
Cables
361
Repeater Receiver COR
361
Repeater Transmitter PTT
363
Repeater Receiver Audio
364
Repeater Transmitter Audio
365
Repeater CTCSS Decoder
366
Control Receiver COR
367
Control Receiver Audio
368
DC Power
368
Logic Inputs
369
Logic Outputs
369
Telephone Line Connection
370
FCC Part 68 Rules
371
Input and Output Connectors
373
Audio Level Potentiometers
374
Message Level Potentiometers
375
DIP Switches
376
Testing the Controller-To-Repeater Transmitter Interface
376
Testing the Controller-To-Repeater Receiver Interface
377
Testing the DTMF Decoder
377
Command Sources
378
Local Control
378
Performing the Tests
378
Falsing
379
Real-Time Clock
379
Parts Lists and Schematics
381
Controller Main Board
381
Speech Synthesizer Module (SSM
390
Telephone Interface Module (TIM
393
Audio Delay Module (ADM
397
5
Based on 1 rating
Ask a question
Give review
Questions and Answers:
Need help?
Do you have a question about the S-COM 7K and is the answer not in the manual?
Ask a question
S-COM 7K Specifications
General
Brand
S-COM
Model
7K
Category
Controller
Language
English
To Next PageTo Next PageTo Previous PageTo Previous Page
Loading...
Need help?
General
