S-COM 7K - DTMF Custom Changes (Duration Gap Pause)

To Next Page

To Previous Page

Programming Tables

A-9

DTMF Custom Changes

(Duration Gap Pause)

Control Character 9950

DTMF Custom Change Code Data Digit

custom DTMF duration change (10990mS) 50xx 0199 x 10mS

custom DTMF duration change (1009900mS) 51xx 0199 x 100mS

custom DTMF gap change (10990mS) 52xx 0199 x 10mS

custom DTMF gap change (1009900mS) 53xx 0199 x 100mS

custom DTMF pause (10990mS) 54xx 0199 x 10mS

custom DTMF pause (1009900mS) 55xx 0199 x 100mS

to ignore each custom DTMF change code enter 00 for xx in any

of above codes
