S-COM 7K - Page 350

7K • Appendix A
A-50
Command Quick Reference
Page Command Name Form and Data Digit Default User
20-1
User Timers
20-2 Set Timer Timeout (PW) 49 xx 03 yyyy *
xx = timer number, 00-09
yyyy = timeout
(0001-6553) = 0.1-655.3 seconds
1.0 second
20-3 Assign Timer Event Macro (PW) 49 xx 02 (macro name)*
xx = timer number, 00-09
none
20-3 Unassign Timer Event Macro (PW) 49 xx 02 *
xx = timer number, 00-09
none
20-4 Stop Timer (PW) 49 xx 00 *
xx = timer number, 00-09
none
20-5 Start/Restart Timer (Retriggerable) (PW) 49 xx 01 *
xx = timer number, 00-09
none
20-6 Start Timer (One-Shot) (PW) 49 xx 04 *
xx = timer number, 00-09
none
21-1
Remote Base
21-2
Remote Base Configuration
21-4 Assign Remote Base Password (PW) 39 02 (new password)* 98
21-5 Select Remote Base Access-Triggered
Macro
(PW) 26 91 (macro name) *
Note: invoked by Access Remote
Base command.
none
21-6 Select Remote Base Dump-Triggered
Macro
(PW) 26 90 (macro name) *
Note: invoked by Dump Remote
Base command.
none
21-6 Select Remote Base Off Message (PW) 31 60 (message) * OFF in CW
21-6 Review Remote Base Off Message (PW) 34 60 * OFF in CW
21-7 Reset RBI-1 (PW) 39 91 * none
21-8 Enable/Disable Remote Base -- Control
Operator
(PW) 63 71 x *
0 = OFF (disabled)
1 = ON (enabled)
Note: used by the Control Operator to
enable/disable the remote base.
Note: Remote Base enabled when
(En71 AND (En72 OR En73)) = TRUE.
OFF
disabled
21-8 Enable/Disable Remote Base --
Scheduler
(PW) 63 72 x *
0 = OFF (disabled)
1 = ON (enabled)
Note: used by the Scheduler to
enable/disable the remote base.
Note: Remote Base enabled when
(En71 AND (En72 OR En73)) = TRUE.
ON
enabled
21-8 Enable/Disable Remote Base -- Control
Operator Override Scheduler Disable
(PW) 63 73 x *
0 = OFF (disabled)
1 = ON (enabled)
Note: used by the Control Operator to
override a scheduler disable of the
remote base.
Note: Remote Base enabled when
(En71 AND (En72 OR En73)) = TRUE.
OFF
disabled
