7K • Appendix D

D-14

Diodes

1N4002 2 D5, D6

1N4732 4.7V 4 D1, D2, D4, D12

1N4735 6.2V 1 D7

1N914 5 D3,D8, D9, D10, D11

ICTE-15/MPTE-15 1 M1

Transistors

2N3904 2 Q2, Q3

2N3906 1 Q1

Integrated Circuits

CD4053 1 U2

CLM6500 2 VR1, VR2

ICM7555 1 U4

LCA110/LH1056 1 U5

LMC660/TLC274 2 U1, U3

TCM1520A 1 U7

TIL181 1 U6

Gas Discharge Tubes

DSA301LS-270 3 E1, E2, E3

Transformers

SPT-109 1 T1

Ferrite Beads

2943666661 2 L1, L2

Connectors

14-pin (dual 7) header 1 J1

ribbon cable assembly 1

modular jack 66011-001 1 J2

6-pin IC socket 2 (for U5, U6)

8-pin IC socket 2 (for U4, U7)

14-pin IC socket 2 (for U1, U3)

16-pin IC socket 1 (for U2)

Hardware

PC board 1
