RTC
®
5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
245
innovators for industry
(05
H
) Code
L
Returned Data Signal Type
12
H
Actual Z axis position / bit [–2
19
… 2
19
–1] (only for intelliWELD
®
with
varioSCAN FC; not with varioSCAN FC i)
This data signal can only be read via the channel of the scan head
connector to which the Z axis is connected.
14
H
Galvanometer scanner temperature / 160
-1
°C [–2
19
… 2
19
–1]
15
H
Servo board temperature / 160
-1
°C [–2
19
… 2
19
–1]
16
H
AGC voltage (PD supply voltage) / 1600
-1
V [–2
19
… 2
19
–1]
17
H
DSP core supply voltage (1.8 V) / 1600
-1
V [–2
19
… 2
19
–1]
18
H
DSP IO voltage (3.3 V) / 1600
-1
V [–2
19
… 2
19
–1]
19
H
Analog section voltage (9 V) / 1600
-1
V [–2
19
… 2
19
–1]
1A
H
AD converter supply voltage (5 V) / 1600
-1
V [–2
19
… 2
19
–1]
1B
H
AGC current (PD supply current) / 16
-1
mA [–2
19
… 2
19
–1]
1D
H
Relative heating output of the corresponding galvanometer scanner
heater (not relevant for intelliSCAN
®
7, intellicube
®
, dynAXIS
®
XS and
scan systems with water-cooled scanners)
Bits #4…19 Relative heating output / ‰ [0 … 1000]
Bits #0…3 = 0
1E
H
Serial number (lower 16 bits)
Bits #4…19 Serial number (lower 16 bits) [0 … 2
16
–1]
Bits #0…3 = 0
1F
H
Serial number (higher 16 bits)
Bits #4…19 Serial number (higher 16 bits) [0 … 2
16
–1]
Bits #0…3 = 0
20
H
Article number (lower 16 bits)
Bits #4…19 Article number (lower 16 bits) [0 … 2
16
–1]
Bits #0…3 = 0
21
H
Article number (higher 16 bits)
Bits #4…19 Article number (higher 16 bits) [0 … 2
16
–1]
Bits #0…3 = 0
22
H
Firmware version number
Bits #4…19 Version number [0 … 2
16
–1]
Bits #0…3 = 0
23
H
Calibration angle (mechanical scan angle (±) for 96% of the maximum
and minimum control value, i.e. for ±503316 bit)
Bits #4…19 Calibration angle / 10
–3
° [0 … 2
16
–1]
Bits #0…3 = 0
24
H
Aperture
Bits #4…19 Aperture / mm [0 … 2
16
–1]
Bits #0…3 = 0
Ctrl Command control_command
