RTC
®
5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
246
(05
H
) Code
L
Returned Data Signal Type
25
H
Wavelength
Bits #4…19 Wavelength / nm [0 … 2
16
–1]
Bits #0…3 = 0
26
H
Tuning number (as of Firmware Version 2078)
Bits #12…19 Start setting
Bits #4…11 Current setting
Bits #0…3 = 0
27
H
only after control_command(
Data
= 17FF
H
): Number of the internally
(e.g. via Code = 17FF
H
for reinstatement via Code = 1700
H
) buffered,
specified to be returned data type (as of Firmware Version 2078)
Bits #12…19 = 0
Bits #4…11 Temporarily stored setting
Bits #0…3 = 0
28
H
Current operational state (flags B15 … B0):
Bit #19 (MSB) (B15) = 1: Galvanometer scanner’s output stage is on
Bit #18 (B14) = 1: Galvanometer scanner heater’s output stage is on
(always 0 for intelliSCAN
®
7, intellicube
®
, dynAXIS
®
XS and
scan systems with water-cooled scanners)
Bit #17 (B13) = 1: Internal voltages normal
Bit #16 (B12) = 1: Position error within normal range
Bit #15 (B11) = 1: Galvanometer scanner and servo board temperature within
normal range
Bit #14 (B10) = 1: Booting process completed
Bit #13 (B9) = 0: A critical error occurred. The system was switched into a
permanent error state.
Bit #12 (B8) = 0: The external power supply voltages have – at least temporarily
– dropped below the allowed value
Bit #11 (B7) = 0: The temperature in the scan system exceeds the maximum
allowed value. The system was switched into a temporary error
state.
Bit #10 (B6) = 1: The AD converter was successfully initialized
Bit #9 (B5) = 0: The galvanometer scanner has reached a critical edge position
Bit #8 (B4) = 1: All control parameters valid
Bit #7 (B3) Reserved (for intelliWELD
®
: 1 = currently no INTERLOCK error)
Bit #6 (B2) Reserved (for intelliWELD
®
: 1 = The sensor board was recognized)
Bit #5 (B1) Reserved
Bit #4 (B0) = 1: The control is activated, as soon as all necessary flags are set
Bit #0…3 = 0
