RTC
®
5 PC Interface Board
Rev. 1.9 e
10 Commands And Functions
248
innovators for industry
(05
H
) Code
L
Returned Data Signal Type
34
H
Sensor board operating temperature
Bits #4…19 Operating temperature / 0.1°C [0 … 65535]
Bits #0…3 = 0
35
H
Emerging-beam-opening temperature
Bits #4…19 Temperature / 0.05°C [0 … 2250]
Bits #0…3 = 0
36
H
Temperature of mirror 2
Bits #4…19 (Temperature + 26.6°C) / 0.05°C [0 … 2250]
Bits #0…3 = 0
37
H
Temperature of mirror 1
Bits #4…19 (Temperature + 26.6°C) / 0.05°C [0 … 2250]
Bits #0…3 = 0
38
H
Protective-window temperature
Bits #4…19 Temperature / 0.044°C [0 … 2250]
Bits #0…3 = 0
39
H
Collimator temperature
Bits #4…19 Temperature / 0.05°C [0 … 2250]
Bits #0…3 = 0
3A
H
Galvanometer-mount temperature
Bits #4…19 Temperature / 0.05°C [0 … 2250]
Bits #0…3 = 0
3B
H
Coolant-flow rate
Bits #4…19 (Coolant-flow rate + 5.51 l·min
-1
) / (0.00595 l·min
-1
) [0 … 2250]
(for T=20°C and a flow rate larger than 3 l·min
-1
)
Bits #0…3 = 0
3C
H
Protective-window scattered light value
Bits #4…19 Scattered light value / 10
-3
V [0 … 2250]
Bits #0…3 = 0
3D
H
Flags sensor board
(*)
if “1” then an INTERLOCK error is initiated
Bit #19 (MSB) = 1: Protective-window temperature value not in [0 … 1882]
Bit #18 = 1: Temperature of mirror 1 value not in [0 … 2250]
Bit #17 = 1: Temperature of mirror 2 value not in [0 … 2250]
Bit #14
(*)
= 1: Emerging-beam-opening temperature value not in [0 … 1200]
Bit #7 = 1: Protective-window scattered light value not in [0 … 2250]
Bit #6 = 1: Coolant-flow rate value not in [750 … 2250]
Bit #5
(*)
= 1: Galvanometer-mount temperature value not in [0 … 1600]
Bit #4
(*)
= 1: Collimator temperature value not in [0 … 2000]
Bits #0…3 = 0
3F
H
Position value scale factor setting (as of Firmware Version 2072)
Bits #6…19 Reserved
Bits #4, 5 Scale factor = 1/2
n
with n = 2 · bit #5 + bit #4
Bits #0…3 = 0
Ctrl Command control_command
