RTC
®
5 PC Interface Board
Rev. 1.9 e
18 Revision History
615
Changes from revision 1.3 to revision 1.4
Page Name of section / command Change
96 chapter 7.1.3 "Marking Points" Added (as of version OUT 527): Marking points via mark or
arc commands of zero length
156 chapter 8.1.5 "Jump Mode" Added
190 chapter 8.7.9 "Monitoring
Processing-on-the-fly Corrections"
revisions and additions to the section "Customer-Defined
Monitoring Area and Conditional Command Execution (as of
Version DLL 525, OUT 527)"
197 chapter 8.9 "Microvector
Commands"
Added
217 chapter "Normal, Short and Variable
List Commands and List Multi-
Commands"
Added (as of version DLL 525, OUT 527): Postponing short
list commands via list_continue (alternative to list_nop)
240 clear_fly_overflow command Added
270 get_jump_table command Added
273 get_marking_info command Change (as of version DLL 525, OUT 527): bits#4…7
300 … if_fly_x_overflow command,
if_fly_y_overflow command,
if_not_fly_x_overflow command,
if_not_fly_y_overflow command
Added
304 … if_not_pin_cond command,
if_pin_cond command
New note about reliable usage page 213
317 list_continue command Added
335 load_jump_table_offset command Added
349 … mark_abs command and the
corresponding _rel, _3d and para_
commands (but not the
corresponding timed commands)
Change (as of version OUT 527): A mark of zero length only
does not change the laser control signals if it occurs within a
polyline (see page 102).
365 measurement_status command Added:
Pos
= 2
32
–1
366 micro_vector_abs command,
micro_vector_rel command
Added
405
… 475
Commands for coordinate transfor-
mations: set_angle, set_angle_list,
set_offset, set_offset_list,
set_offset_xyz, set_offset_xyz_list,
set_matrix, set_matrix_list,
set_scale. set_scale_list
Changed: behavior for
at_once
= 3 (here the laser control
signals remain unaffected)
425 set_fly_limits command Added
436 set_jump_mode command Added
438 set_jump_mode_list command Added
439 set_jump_table command Added
498 set_vector_control command Change (as of version DLL 525, OUT 527): Variation of the
focus shift with
Ctrl
= 7
